More than 70 installed PET-based cameras worldwide: ensuring reliable systems with matured technology, supported by proven and experienced service and application network
Highest PET resolution (using the industry’s most advanced pixelated modular LYSO detectors)
Exceptionally high count rate tolerance supporting high activity studies of multiple animals or short half-life isotopes
State-of-the-art Tera-TomoTM 3D PET image reconstruction engine
Touchscreen interface
Shared interface for PET and CT
Imaging chamber movement control through touchscreen interface or from the acquisition workstation
Continuous physiological monitoring
PET persistence scope function
Animal handling
Direct access to the animal during scan
Zero dead space: easy manipulation of the animal (injection, blood sampling, etc.)
Automated imaging chamber positioning – Integrated heating and gas anesthesia possibility
Physiological monitoring
ECG/respiratory gating
PET Detector
LYSO crystal full ring geometry
Up to 12 cm transaxial FOV
Aperture: up to 16 cm
Up to 0.3 mm3 spatial resolution by Tera TomoTM 3D PET reconstruction engine
High Precision Gantry
Precise and robust rotational bearing and drive
Exceptionally stable gantry with 3 axis movements
Large bore size up to 160 mm
Touchscreen interface
Vibration free rubber pads
X-Ray CT System
80 W X-ray tube power
Up to 1 mA tube current
<10 mGy exposure CT dose
2-12 cm variable TFOV
Up to x 7,6 zoom
≤ 10 µm isotropic voxel size
For more information, click on more info
